Tongue & Groove Double Swing Gates

Premium Design

For greatest privacy. All the benefits of all aluminium gates, in a solid infill gate. Your choice of vertical or horizontal alignment of the Tongue and Groove. NOT SUITABLE FOR HIGH WIND ZONES


Contact with your dimensions for a price

Aluminium construction.

Frame Length: 1m to Approx 2.4m per wing for double swing ( 4.8m ) Single swing options are also available.

Please note that these gates are big and strong but will in most situations require a suitable post and footing to swing gates this size; Steel 100mm RHS Powdercoated posts are available from us starting at $225.00 each. Please ask us about these.

Frame height: 1m to 1.8m (based on an installed gate)

Sides and top rail: 50 x 50mm

Bottom rail: 100 x 50mm

Tongue and groove: 127mm wide each framed with special screw fastened profile

Layout: Horizontal or vertical

Hinges: Clamp style hinges or in some cases for larger gates we have heavy duty weld on hinges


The standard colour option for this gate style is Matte Black. For other colour options please read through our powder colour page here.


Delivery cost: TBA Depending on location.


To get a quote for your gate, please confirm by phone or email your delivery address, name and contact number. We will need your distance between your current posts and the finished height you want. If you do not have posts please tell us as we can also quote on alloy or steel ones. Please also check if there is any slope to the current driveway (left to right of the posts) as this will affect the quote and the finished look of the gate.
